Key Technical Specifications:
Current Measurement
-
AC Current Range: 600 A AC.
-
DC Current Range: 900 A AC.
- Ideal for a wide range of current measurement needs, from low to high currents.
Voltage Measurement
-
AC Voltage Range: 0.15V to 1000V.
-
DC Voltage Range: 0.15V to 1400V.
- Suitable for both low-voltage and high-voltage electrical systems.
True RMS Technology
- Ensures accurate measurements of distorted waveforms and non-linear signals.
Frequency Measurement
-
Range: 20Hz to 3kHz, covering a broad spectrum of electrical systems.
Continuity and Diode Testing
- Features a continuity buzzer for quick circuit checks and diode testing functionality.
Inrush Current Measurement
- Captures high startup currents for motors, transformers, and industrial equipment.
Power Measurement
- Measures Active Power, Apparent Power, and Reactive Power for advanced power system diagnostics.
Safety Ratings
-
CAT IV 600V and CAT III 1000V certified, providing high-level safety for professional use.
Jaw Opening Size
-
34mm (1.34 inches): Accommodates cables and busbars of various sizes..
Display Features
- High-resolution backlit LCD display for clear visibility in all lighting conditions.
Durability and Design
- Robust and ergonomic design for reliable use in demanding industrial environments.
- Lightweight and portable for easy handling.
Features:
-
True RMS Measurement: Ensures accurate readings even with distorted waveforms, crucial for modern electrical systems with harmonics.
-
Wide Measurement Range: Capable of measuring a broad spectrum of AC/DC currents, covering a wide range of applications.
-
High Accuracy: Delivers precise measurements with minimal error, increasing the reliability of your readings.
-
Compact and Lightweight: Portable and easy to use in tight spaces, making it ideal for field service and maintenance.
-
Backlit Display: Ensures clear visibility of readings in low-light conditions.
-
Auto Ranging: Automatically selects the appropriate measurement range for optimal accuracy and convenience.
-
Low Battery Indication: Alerts the user when battery power is low, preventing unexpected shutdowns.
-
Safety Features: Equipped with safety features to protect the user from electrical hazards.
-
Ergonomic Design: Comfortable to hold and use for extended periods, reducing user fatigue.
