Key Technical Specifications:
-
AC Current Measurement: Accurately measures up to 1000A AC for a wide range of electrical and industrial applications.
-
Voltage Measurement: Measures AC/DC voltage up to 600V for versatile diagnostics.
-
Resistance and Continuity Testing: Measures resistance up to 40MΩ and includes audible continuity for quick connection checks.
-
Capacitance Measurement: Reads capacitance up to 4,000µF, suitable for troubleshooting motors and capacitors.
-
Frequency Measurement: Supports frequency measurement from 10Hz to 1kHz for electronic diagnostics.
-
Clamp Jaw Opening: Fits conductors up to 43mm (1.7 inches) in diameter, making it suitable for larger cables.
-
Data Hold Function: Retains readings on the display for easy recording and analysis.
-
Min/Max Function: Captures and displays the minimum and maximum values for monitoring fluctuations.
-
Backlit LCD Display: Features a large, backlit screen for clear visibility in dimly lit environments.
-
Auto Power Off: Saves battery life by automatically turning off the device when idle.
-
Safety Rating: Certified with CAT III 600V for safe use in high-energy environments.
-
Rugged Build: Durable and robust construction designed for demanding field applications.
-
Included Accessories: Includes test leads, Type K thermocouple probe for temperature measurement, carrying case, and 9V battery.
