Key Technical Specifications:
Current Measurement
-
AC Current Range: 0.060A to 600.0A.
- Capable of handling low and high current systems accurately.
Voltage Measurement
-
AC Voltage Range: 80.0V to 600.0V.
- Compatible with standard and high-voltage electrical systems.
True RMS Technology
- Ensures precise readings even for distorted waveforms and non-linear loads.
Power Factor and Phase Angle
- Measures Power Factor (PF) and Phase Angle for advanced power quality analysis.
Harmonic Measurement
- Analyzes up to the 30th harmonic, allowing detection of waveform distortions.
Jaw Opening Size
-
46mm (1.8 inches): Accommodates large-diameter cables and busbars.
Data Logging and Connectivity
- Wireless capability via GENNECT Cross App for data transfer, visualization, and reporting (requires optional adapter).
Durability and Design
-
IP54-rated dustproof and waterproof design for rugged field use.
- Compact and lightweight for easy portability.
Display Features
- Large, easy-to-read backlit LCD display for clear visibility in low-light conditions.
Key Features:
-
True RMS Power Measurement: Accurately measures true power (Watts) even in non-linear loads, providing critical insights into energy consumption.
-
Simultaneous Measurement: Measures key parameters simultaneously, including current, voltage, power, power factor, and energy consumption, for a comprehensive understanding of electrical systems.
-
Wide Measurement Range: Capable of measuring a wide range of AC currents, covering a variety of applications from small appliances to large industrial equipment.
-
High Accuracy: Delivers precise measurements with minimal error, ensuring reliable data for energy analysis and troubleshooting.
-
Compact and Lightweight: Portable and easy to use in tight spaces, making it ideal for field service and maintenance.
-
Large, Backlit Display: Ensures clear visibility of readings in various lighting conditions.
-
Data Logging Capability: Stores measurement data for later analysis and reporting, helping to identify energy-saving opportunities.
-
Bluetooth Connectivity: Enables wireless data transfer to mobile devices or computers for easy data management and analysis.
-
Long Battery Life: Provides extended operation time on a single charge, minimizing downtime.
-
Safety Features: Equipped with safety features to protect the user from electrical hazards.
