Key Technical Specifications
-
DC Voltage:
- Range: 600mV - 600V
- Accuracy: ±0.5%
-
AC Voltage:
- Range: 600mV - 600V
- Accuracy: ±1.0%
-
DC Current:
- Range: 600uA - 10A
- Accuracy: ±1.0%
-
AC Current:
- Range: 600uA - 10A
- Accuracy: ±1.5%
-
Resistance:
- Range: 600Ω - 60MΩ
- Accuracy: ±1.0%
-
Frequency:
- Range: 99.99kHz
- Accuracy: ±1.0%
-
Capacitance:
- Range: 9.999nF - 99.99uF
- Accuracy: ±2.0%
-
Diode Test: Yes
-
Continuity Test: Yes
-
Data Hold: Yes
-
Relative Mode: Yes
-
Auto Power Off: Yes
-
Power Supply: 9V battery
-
Safety Rating: CAT III 600V, CAT II 1000V
Key Features
-
True RMS Measurement: Provides accurate readings of complex waveforms, including distorted signals.
-
High Accuracy: Delivers precise and reliable measurements with high resolution.
-
Compact and Portable: Lightweight and pocket-sized for easy carrying and storage.
-
Large, Easy-to-Read Display: Clear LCD screen for easy viewing in various lighting conditions.
-
Fast Measurement Speed: Enables quick and efficient troubleshooting.
-
Circuit-Breaker False Trip Prevention: Minimizes the risk of accidental circuit breaker trips during measurements.
-
Low-Pass Filter: Reduces the impact of high-frequency noise on measurements.
-
Auto Power Save: Conserves battery life by automatically powering off the meter when not in use.
-
Rugged and Durable: Designed to withstand drops and other impacts.
Ideal for:
-
Industrial Maintenance: Troubleshooting and diagnosing electrical and electronic equipment.
-
Field Service: Performing maintenance and repair work in various field applications.
-
HVAC/R Technicians: Diagnosing and repairing HVAC/R systems.
-
Electricians: Verifying electrical installations and ensuring safety.
